Ubiquiti 24V 24W PoE Adapter White POE-24-24W-WH

Ubiquiti 24V 24W PoE Adapter White POE-24-24W-WH

Ubiquiti's POE-24-24W-WH is a 24V, 1A, PoE injector. The unit features Electrostatic Discharge (ESD) protection, surge protection, clamping protection, peak pulse current and maximum surge discharge, all of which aid in protecting your PoE devices.

• Please note: Power Cable Not Included

Technical Specification

Output voltage: 24V DC @ 1.0A

LAN activity indicator: No

Gigabit LAN port: No

Remote reset capability: Yes

Reset button: Yes

Rated voltage: 100-240V AC @ 50/60Hz

Input current: 0.6A @ 120V AC, 0.4A @ 240V AC

Inrush current: <60A peak @ 120V AC, <120A peak @ 230V AC

Efficiency: 80+%

Output ripple: 1% Max.

Switching frequency: 65 kHz

Line regulation: ≤ 3%

Load regulation: ≤ 5%

2-pair powering: Pins 4, 5 (+) and pins 7, 8 (-)

4-pair powering: -

Data IN / PoE: RJ45 shielded socket

Surge protection: Difference and common mode

Clamping protection: 11V data, 60V power

Max. surge discharge: 1500A (8/20 μs) power

Peak pulse current: 36A (10/1000 μs) data

Shunt capacitance: <5 pF data

Response time: <1 ns

Dimensions: 88 x 57 x 33 mm

Weight: 159 g
